| Detail: | 1-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card |
| Model: | HWIC-1T |
| Condition: | In Stock |
| Related: | |
| Warranty: |
1 Year-Warranty
100% Money-back
Free After-Sales Service
|
| Shipping: |
Air Shipping to
United States
, Most Customers Receive during 5-7 Days
?
If you finish the payment today,
your order will arrive within the estimated delivery time. |
| Ships to:
1.2
|
2-7 Days
US$
|
| Payment: |
More
|
(Note: Cisco discount and Stock always changed, we will try most effort to follow it but can not ensure every web was changed accordingly. So Our Products Service will contact you after order if meet such special condition.)
Serial and asynchronous high-speed WAN interface cards (HWICs) provide highly flexible connections for Cisco1800, 1900, 2800, 2900, 3800, and 3900 Series Integrated Services Routers. These HWICs help customers enable applications such as WAN access, legacy protocol transport, console server, and dial access server. You can mix and match HWICs to tailor cost-effective solutions for common networking problems such as remote network management, external dial-modem access, low-density WAN aggregation, legacy protocol transport, and high-port-density support.
Cisco offers four new serial and asynchronous HWICs:
Cisco 1-Port T1/Fractional T1 DSU/CSU WAN Interface Card (HWIC-1DSU-T1)
Cisco 1-Port Serial WAN Interface Card (HWIC-1T)
Cisco 2-Port Serial WAN Interface Card (HWIC-2T)
Cisco 2-Port Asynchronous/Synchronous Serial WAN Interface Card (HWIC-2A/S)
Model | HWIC-1T |
Synchronous Support | Yes |
Synchronous Maximum Speed (Per Port) | 8 Mbps |
Asynchronous Support | Yes |
Asynchronous Maximum Speed (Per Port) | 115.2 kbps |
Bisync Support | Yes |
Serial Protocols | EIA-232, EIA-449, EIA-530, EIA-530A, V.35, and X.21 |
Network Clock Synchronization | Yes |
NEBS | Type 2/4 |
Do you have any question about the HWIC-1T?
Contact us now via info@hi-network.com
Manufacturer | Cisco |
Part Number | HWIC-1T |
Device Type | Expansion module |
Form factor | Plug-in module |
Specifications | |
Synchronous Support | Yes |
Synchronous Maximum Speed (Per Port) | 8 Mbps |
Asynchronous Support | Yes |
Asynchronous Maximum Speed (Per Port) | 115.2 kbps |
Bisync Support | Yes |
Serial Protocols | EIA-232, EIA-449, EIA-530, EIA-530A, V.35, and X.21 |
Network Clock Synchronization | Yes |
NEBS | Type 2/4 |
TelecommPTT | TBR1 and 2 JATE Digital NEBS |
Safety Approvals | UL 60950, CAN/CSA 22.2, CSA60950, GB 4943, AS/NZS 60950, EN60950, IEC 60950 |
Immunity | EN300386, CISPR24, EN55024, EN50082-1, 61000-4-2/3/4/5/6/8/11 |
Emissions | FCC Part 15 Class A, ICES-003 Class A, EN55022 Class A, CISPR22 Class A, AS/NZSCISPR22 Class A, VCCI Class A, EN 300386, EN61000-3-2/3, CNS13438 |
Physical Specifications | Singlewide HWIC, no slot restrictions Dimensions (H x W x D) 0.8 x 3.1 x 5.6 in. (2.1 x 7.9 x 14.2 cm) |
Environmental Specifications | Operating temperature: 32 to 104°F (0 to 40°C) NEBS short-term operating temperature: 32 to 131°F (0 to 50°C) Storage temperature: -4 to 149°F (-20 to 65°C) Relative humidity: 10 to 90%, noncondensing |
TelecommPTT | • TBR1 and 2 • JATE Digital • NEBS |
Safety Approvals | • UL 60950 (United States) • CAN/CSA 22.2, CSA60950 (Canada) • GB 4943 (China) • AS/NZS 60950 (Australia/New Zealand) • EN60950 (Europe) • IEC 60950 (International) |
Immunity | • EN300386 • CISPR24 • EN55024 • EN50082-1 • 61000-4-2/3/4/5/6/8/11 |
Emissions | • FCC Part 15 Class A • ICES-003 Class A • EN55022 Class A • CISPR22 Class A • AS/NZSCISPR22 Class A • VCCI Class A • EN 300386 • EN61000-3-2/3 • CNS13438 |
Physical Specifications | • Singlewide HWIC, no slot restrictions • Dimensions (H x W x D) 0.8 x 3.1 x 5.6 in. (2.1 x 7.9 x 14.2 cm) |
